The Geek+ P500R is a shelf-to-person picking robot: it drives beneath a storage rack, raises the whole shelf 60 mm off the floor, and carries it to a stationary picking operator. The operator never walks the aisles, and the racks themselves become the moving part of the warehouse.

Its working envelope is deliberately compact. A 950 x 702 x 275 mm chassis weighing 144 kg handles shelves up to 880 x 880 mm and payloads to 600 kg, travelling at 2 m/s empty and 1.5 m/s under load. The shelf is off the ground in four seconds, so the cycle penalty at each pick face stays small.

That combination suits small to mid-size fulfilment operations — e-commerce, spare parts, pharmacy and retail replenishment — where the stock is many small items across many SKUs rather than a few heavy pallets. Where racks or loads are larger, the P800R and P1200R cover the same workflow at higher capacity.

Key Capabilities

• 600 kg Shelf Payload: Lifts a fully loaded storage rack of up to 600 kg and moves it to the operator, so pickers stay at one station instead of walking the aisles.
• Compact 950 x 702 mm Footprint: The smallest chassis in the Geek+ P picking family, allowing narrower aisles and denser rack layouts than the P800R or P1200R.
• 4-Second Lift Cycle: Minimum lifting time of four seconds keeps the pause at each rack short, which matters when a robot performs hundreds of lifts per shift.
• 2 m/s Unloaded Travel: Runs at 2 m/s without a shelf and 1.5 m/s under load, so repositioning between tasks does not dominate the cycle.
• Racks to 880 x 880 mm: Sized for the shelf format typical of small-item picking; larger rack footprints are handled by the P800R and P1200R.
• 144 kg Robot Mass: Light enough for conventional warehouse floor loading while still rated for a 600 kg shelf.

This model is offered on a quotation basis. Fleet size, rack and tote dimensions, control-system integration, and delivery schedule all change the final figure, so pricing is confirmed per project rather than listed.

Buying through Robotix Market

This unit is sourced new through established distribution channels and ships worldwide with the full manufacturer warranty. Technical support is coordinated with the manufacturer's own service network. Deployment scope, configuration, fleet software, and commissioning responsibilities are agreed as part of the quotation — on-site installation is not included in the product price.
